Drone Mapping Tools

Emlid Reach RS2 GNSS Receiver

Regular price $2,499.00 USD
Regular price Sale price $2,499.00 USD
Sale Sold out

Professional multifrequency L1 / L2 / L5 GNSS RTK / PPK geodesic receiver

Gets a fix
in seconds

Reach RS2 gets a fixed solution in just seconds and maintains robust performance even in challenging conditions. Centimeter accuracy can be achieved on distances up to 60 km in RTK, and 100 km in PPK mode.

GPS, GLONASS, BeiDou,
Galileo, and QZSS

L1OF, L2OF, L1C/A, L2C,
E1B/C, E5b, B1I B2I

PPP
support

RINEX raw data logs are compatible with PPP services so you can now get centimeter-precise results in any place on Earth. Process RINEX files in an online service and get position with absolute accuracy.


Built-in
3.5G modem

Reach RS2 features a power-efficient 3.5G HSPA modem with 2G fallback and global coverage. Now corrections can be accessed or broadcasted over NTRIP independently, without relying on an Internet connection on your phone.


22 hours
on 1 charge

Up to 22 hours of autonomous work when logging data and up to 16 hours as a 3G rover, even in cold weather—no more need to carry spare batteries with you. Reach RS2 can charge from a USB wall charger or a power bank over USB-C.



Specifications
627 kb

Mechanical

  • Dimensions126x126x142 mm
  • Weight950 g
  • Operating tº-20…+65 ºC
  • Ingress protectionIP67 (water and dust)

Electrical

  • Autonomy16 hrs as 3.5G RTK rover,
    22 hrs logging
  • BatteryLiFePO4 6400 mAh, 6.4 V
  • External power input6–40 V
  • ChargingUSB Type-C 5 V, 2 A
  • CertificationFCC, CE

Positioning

  • StaticH: 4 mm + 0.5 ppm
    V: 8 mm + 1 ppm
  • PPKH: 5 mm + 0.5 ppm
    V: 10 mm + 1 ppm
  • RTKH: 7 mm + 1 ppm
    V: 14 mm + 1 ppm
  • Convergence time~5 s typically

Connectivity

  • LoRa radio
  • Frequency range868/915 MHz
  • Power0.1 W
  • DistanceUp to 8 km
  • 3.5G modem
  • RegionsGlobal
  • BandsQuad-band, 850/1900,
    900/1800 MHz
  • SIM cardNano-SIM
  • Wi-Fi802.11b/g/n
  • Bluetooth4.0/2.1 EDR
  • PortsRS-232, USB Type-C

Data

  • CorrectionsNTRIP, VRS, RTCM3
  • Position outputNMEA, LLH/XYZ
  • Data loggingRINEX with events
    with update rate up to 10 Hz
  • Internal storage16 GB
    160+ days of logging at 1 Hz

GNSS

  • Signal trackedGPS/QZSS L1C/A, L2C
    GLONASS L1OF, L2OF
    BeiDou B1I, B2I
    Galileo E1-B/C, E5b
  • Number of channels184
  • Update rates10 Hz GNSS
  • IMU9DOF
